TSC TTP-244 Pro Series User Manual

1. Introduction
1.1 Product Introduction
Thank you very much for purchasing TSC bar code printer.
The TTP-244 Pro offers the largest media and ribbon capacities in its class. Unlike most
printers, it can easily handle both a 300-meter ribbon and a full 8-inch OD roll of labels.
With its fast 5 inch per second print speed, along with the largest memory capacity in its
class, the TTP-244 Pro easily outperforms the competition.
With its small, compact footprint and dual-motor design, the TTP-244 Pro is perfect for a
wide variety of label and tag printing applications – everything from shipping labels to
compliance and general purpose product-identification labels & tags.
The TTP-244 Pro supports PDF417, QRCode, Datamatrix …. two-dimensional barcodes
used to print complex transportation formats – a feature that makes it ideal for automobile
service shops, stock rooms, and walk-in shipping and mail centers.
To print label formats, please refer to the instructions provided with your labeling software;
if you need to write the custom programs, please refer to the TSPL/TSPL2 programming
manual that can be found on the accessories CD-ROM or on TSC website at
http://www.tscprinters.com.
− Applications
 Shipping and receiving
 Compliance labeling
 Asset tracking
 Inventory control
 Document management
 Shelf labeling and product marking
 Specimen labeling and patient tracking

TSC TTP-244 Pro Series Specifications

General

Resolution	203 dpi
Print Method	Thermal Transfer / Direct Thermal
Processor	32-bit RISC CPU
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0
Label Width	1 inch to 4.49 inches
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
Power Supply	External universal switching power supply
Operating Temperature	5 ~ 40°C (41 ~ 104°F)
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
