TSC TTP-244 Pro Series - Interior View

- 11 -
2.2.2 Interior View
1. Printer cover (in open position)
2. PAUSE button
3. PWR., ON-LINE, ERR. indicators
4. FEED button
5. Ribbon supply spindle
6. Fixing tabs
7. Label supply roll spindle
8. Ribbon mechanism
9. Ribbon rewind spindle
10. Printer carriage release lever
11. Media sensor
12. Adjustable label guide
13. Platen
1
3
2
4
US
B
inte
rfa
ce
7
USB
inter
face
6
5
8
9
10
11
12
13
