TSC TTP-244 Pro Series User Manual

- 15 -
3.2 Loading the Media
1. Open the printer cover.
2. Disengage the printer carriage by pulling
the printer carriage release lever on the
left side of the platen.
3. Slide the label supply roll spindle
through the core of a label roll and
attach the fixing tabs onto the spindle.
4. Place the label roll into the label roll
mount/ or external label roll mount. Feed
the label under the carriage and over the
platen.
External Label Roll Mount (Option)

TSC TTP-244 Pro Series Specifications

General

Resolution	203 dpi
Print Method	Thermal Transfer / Direct Thermal
Processor	32-bit RISC CPU
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0
Label Width	1 inch to 4.49 inches
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
Power Supply	External universal switching power supply
Operating Temperature	5 ~ 40°C (41 ~ 104°F)
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
