TSC TTP-244 Pro Series User Manual

- 20 -
3.4 Install SD Memory Card (Option)
1. Open the memory card cover.
2. Plus the SD memory card module on the main board.
3. Install the SD memory card.
4. Close the memory card cover.

TSC TTP-244 Pro Series Specifications

General

Resolution	203 dpi
Print Method	Thermal Transfer / Direct Thermal
Processor	32-bit RISC CPU
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0
Label Width	1 inch to 4.49 inches
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
Power Supply	External universal switching power supply
Operating Temperature	5 ~ 40°C (41 ~ 104°F)
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
