TSC TTP-244 Pro Series User Manual

- 9 -
2. Operations Overview
2.1 Unpacking and Inspection
This printer has been specially packaged to withstand damage during shipping. Please
carefully inspect the packaging and printer upon receiving the bar code printer. Please
retain the packaging materials in case you need to reship the printer.
Unpacking the printer, the following items are included in the carton.
If any parts are missing, please contact the Customer Service Department of your
purchased reseller or distributor.
 One printer unit
 One Windows labeling software/Windows driver CD disk
 One quick installation guide
 One external auto switching power supply
 One power cord
 One label spindle
 Two fixing tabs
 Two ribbon spindles
 One paper core for ribbon rewind spindle

TSC TTP-244 Pro Series Specifications

General

Resolution	203 dpi
Print Method	Thermal Transfer / Direct Thermal
Processor	32-bit RISC CPU
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0
Label Width	1 inch to 4.49 inches
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
Power Supply	External universal switching power supply
Operating Temperature	5 ~ 40°C (41 ~ 104°F)
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
