- 2 -

1.2 Product Features

1.2.1 Printer Standard Features

The printer offers the following standard features.

Product standard feature

Thermal transfer or direct thermal printing

Black mark reflective sensor

Gap transmissive sensor

Ribbon end sensor

2 buttons

3 LED for printer status (Power, Error, On-line)

32-bit RISC CPU

USB 2.0 (full speed) & RS-232 interface

8 MB SDRAM memory

4 MB FLASH memory

Eltron

EPL and Zebra

ZPL emulation languages support

Internal 8 alpha-numeric bitmap fonts

Internal Monotype Imaging

true type font engine with one CG Triumvirate Bold

Condensed scalable font

Fonts and bar codes can be printed in any one of the four directions (0, 90,180,

270 degree)

Downloadable fonts from PC to printer memory

Downloadable firmware upgrades

Bar code, graphics/image printing

Supported bar code

Supported image

1D bar code

2D bar code

BITMAP, BMP, PCX

(Max. 256 colors

graphics)

Code 39, Code 93, Code 128UCC,

Code 128 subset A, B, C, Codabar,

Interleave 2 of 5, EAN-8, EAN-13,

EAN-128, UPC-A, UPC-E, EAN and

UPC 2 (5) digits add-on, MSI,

PLESSEY, POSTNET, RSS-

Stacked, GS1 DataBar, Code 11

DataMatrix,

Maxicode, PDF-417,

Aztec, QR code

Questions and Answers:

Need help?

Do you have a question about the TSC TTP-244 Pro Series and is the answer not in the manual?

TSC TTP-244 Pro Series Specifications

General

Resolution	203 dpi
Print Method	Thermal Transfer / Direct Thermal
Processor	32-bit RISC CPU
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Memory	8 MB SDRAM, 4 MB Flash
Interface	USB 2.0
Label Width	1 inch to 4.49 inches
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
Power Supply	External universal switching power supply
Operating Temperature	5 ~ 40°C (41 ~ 104°F)
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
