TSC TTP-244CE series User Manual

TSC AUTO ID Technology Co., Ltd. 112 Copyright 2009 All Rights Reserved.
 FOR…NEXT LOOP
Description
Loop is used to execute one or more lines of program repetitively. A loop counter value
specifies the number of executions. Nested loops are allowed (up to 39 nested loops) in this
printer. Jumping out in the middle of the FOR…NEXT loop is prohibited.
Syntax
FOR variable = start TO end STEP increment
statement; start < end
NEXT
Parameter Description
variable The variable name is (up to 8 characters)
start Integer or floating point numbers
end Integer of floating point numbers
increment Integer or floating point, positive or negative.
Example
DOWNLOAD "TEST.BAS"
SIZE 3,3
GAP 0.08,0
DENSITY 8
SPEED 4
DIRECTION 1
CLS
FOR I=1 TO 10 STEP 1
TEXT 100,10+30*(I-1),"3",0,1,1,STR$(I)
NEXT
FOR I=1 TO 1000 STEP 100
TEXT 200,10+((I-1)/10)*3,"3",0,1,1,STR$(I)
NEXT
FOR I=110 TO 10 STEP -10
TEXT 300,10+(ABS(I-110))*3,"3",0,1,1,STR$(I)
NEXT
FOR I=1 TO 5 STEP 0.5
IF I-INT(I)=0 THEN Y=10+60*(I-1) ELSE Y=Y+30
TEXT 400,Y,"3",0,1,1,STR$(I)
NEXT
PRINT 1
EOP
TEST
See Also
DOWNLOAD, EOP

TSC TTP-244CE series Specifications

General

Resolution	203 dpi
Processor	32-bit RISC CPU
Print Method	Thermal Transfer / Direct Thermal
Max Print Speed	4 inches per second
Memory	8 MB SDRAM, 4 MB Flash
Communication Interfaces	USB, Serial (RS-232)
Media Handling	Continuous, Fan-Fold
Media Type	Continuous, Die-cut, Black Mark, Fan-fold
Media Width	1 inch to 4.4 inches
Media Roll Diameter	127 mm (5 inches)
Ribbon Length	300 m
Ribbon Core	25.4 mm (1 inch)
Power	100-240 VAC, 50/60 Hz
Weight	2.5 kg
Max Print Length	2, 286 mm (90")
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D) 9.13" (W) x 6.14" (H) x 11.34" (D)
