TSC TTP-244CE series User Manual

TSC AUTO ID Technology Co., Ltd. 43 Copyright 2009 All Rights Reserved.
 CIRCLE
Description
This command draws a circle on the label.
Syntax
CIRCLE X_start, Y_start, diameter, circle thickness
Parameter Description
X_start Specify x-coordinate of upper left corner (in dots)
Y_start Specify y-coordinate of upper left corner (in dots)
diameter Specify the diameter of the circle (in dots)
thickness Thickness of the circle (in dots)
Example
SIZE 80 mm, 30 mm
GAP 0,0
DIRECTION 1
CLS
BAR 250,20,100,1
BAR 250,20,1,100
CIRCLE 250,20,100,1
PRINT 1

TSC TTP-244CE series Specifications

General

Resolution	203 dpi
Processor	32-bit RISC CPU
Print Method	Thermal Transfer / Direct Thermal
Max Print Speed	4 inches per second
Memory	8 MB SDRAM, 4 MB Flash
Communication Interfaces	USB, Serial (RS-232)
Media Handling	Continuous, Fan-Fold
Media Type	Continuous, Die-cut, Black Mark, Fan-fold
Media Width	1 inch to 4.4 inches
Media Roll Diameter	127 mm (5 inches)
Ribbon Length	300 m
Ribbon Core	25.4 mm (1 inch)
Power	100-240 VAC, 50/60 Hz
Weight	2.5 kg
Max Print Length	2, 286 mm (90")
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D) 9.13" (W) x 6.14" (H) x 11.34" (D)
