TSC TTP-244CE series User Manual

TSC AUTO ID Technology Co., Ltd. 144 Copyright 2009 All Rights Reserved.
Device Reconfiguration Commands
 SET COUNTER
Description
Counters can be a real counter or a variable. This setting sets the counter number in the
program and its increments. There are three different types of counters: digit (0~9~0), lower
case letter (a~z~a) or upper case letter (A~Z~A).
Syntax
SET COUNTER @n step
@n = "Expression"
Parameter Description
@n n: counter number. There are 51 counters available (@0~@50)
in the printer.
step The increment of the counter, can be positive or negative.
-999999999 <= step <= 999999999
If the counter is used as a fixed variable, please set the
increment to 0.
Expression Initial string. String length is 101 bytes
Example
SIZE 3,3
GAP 0,0
DENSITY 8
SPEED 6
DIRECTION 0
REFERENCE 0,0
SET COUNTER @1 1
@1="00001"
SET COUNTER @2 5
@2="AB000001"
CLS
TEXT 50,50,"3",0,1,1,@1
BARCODE 50,100,"39",48,1,0,2,4,@2
PRINT 2,1
See Also
PRINT, TEXT, BARCODE

TSC TTP-244CE series Specifications

General

Resolution	203 dpi
Processor	32-bit RISC CPU
Print Method	Thermal Transfer / Direct Thermal
Max Print Speed	4 inches per second
Memory	8 MB SDRAM, 4 MB Flash
Communication Interfaces	USB, Serial (RS-232)
Media Handling	Continuous, Fan-Fold
Media Type	Continuous, Die-cut, Black Mark, Fan-fold
Media Width	1 inch to 4.4 inches
Media Roll Diameter	127 mm (5 inches)
Ribbon Length	300 m
Ribbon Core	25.4 mm (1 inch)
Power	100-240 VAC, 50/60 Hz
Weight	2.5 kg
Max Print Length	2, 286 mm (90")
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D) 9.13" (W) x 6.14" (H) x 11.34" (D)
