TSC TTP-244CE series User Manual

TSC AUTO ID Technology Co., Ltd. 53 Copyright 2009 All Rights Reserved.
 AZTEC
Description
This command is used to define the AZTEC 2D bar code. Supported by V6.60EZ.
Syntax
AZTEC x,y,rotate,[size,]ecp,]flg,]menu,]multi,]rev,]"content"
Parameter Description
x Horizontal start position (in dots)
y Vertical start position (in dots)
rotate Rotation
0: No rotation
90: 90 degrees
180: 180 degrees
270: 270 degrees
size Element module size (1 to 20), default is 6
ecp Error control (& symbol size/type) parameter
0 : default error correction level
1 to 99 : minimum error correction percentage
101 to 104 : 1 to 4-layer Compact symbol
201 to 232 : 1 to 32-layer Full-Range symbol
300 : a simple Aztec "Rune"
flg 0 : input message is straight bytes
1 : input uses "<Esc>n" for FLG(n), "<Esc><Esc>" for "<Esc>"
menu Menu symbol (0 : no, 1 : yes), default is 0
multi Number of symbols (1 to 26), default is 6
rev Output to be reversed (0 : no, 1 : yes), default is 0
content Barcode content
Example
SIZE 3,3
GAP 0,0
SPEED 4
DENSITY 8
DIRECTION 0
REFERENCE 0,0
OFFSET 0.00
SET CUTTER OFF
SET TEAR ON
CLS
AZTEC 200,10,0,"ABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789"
PRINT 1
CLS

TSC TTP-244CE series Specifications

General

Resolution	203 dpi
Processor	32-bit RISC CPU
Print Method	Thermal Transfer / Direct Thermal
Max Print Speed	4 inches per second
Memory	8 MB SDRAM, 4 MB Flash
Communication Interfaces	USB, Serial (RS-232)
Media Handling	Continuous, Fan-Fold
Media Type	Continuous, Die-cut, Black Mark, Fan-fold
Media Width	1 inch to 4.4 inches
Media Roll Diameter	127 mm (5 inches)
Ribbon Length	300 m
Ribbon Core	25.4 mm (1 inch)
Power	100-240 VAC, 50/60 Hz
Weight	2.5 kg
Max Print Length	2, 286 mm (90")
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D) 9.13" (W) x 6.14" (H) x 11.34" (D)
