TSC TTP-244CE series User Manual

TSC AUTO ID Technology Co., Ltd. 85 Copyright 2009 All Rights Reserved.
File Management Commands
 DOWNLOAD
Description
"DOWNLOAD" is a header of the file that is to be saved in the printer's memory. The
downloaded files can be divided into two categories: program files and data files (including
text data files, PCX graphic files and bitmap font files) The detailed descriptions regarding
the download syntax for different files are as follows:
Maximum numbers of file saved in DRAM:
50 files for TSPL/TSPL2 language printers.
Maximum numbers of file saved in Flash memory:
50 files for TSPL language printers
256 files for TSPL2 language desktop printers (TTP/TDP-245 / TTP-343 / TTP-244)
256 files for TSPL2 language industrial printers (TTP-246M/344M)
Model
Maximum numbers of file saved in
DRAM
FLASH
Ext. FLASH
TTP-243
50
50
256
TTP-243E
50
50
256
TTP-243 Plus
50
256
256
TTP-243E Plus
50
256
256
TTP-244ME
50
50
256
TTP-244ME Plus
50
256
256
TTP-244
50
256
--
TTP-244 Plus
50
256
Depends on SD
card capacity
TTP-244CE
50
256
--
TTP-245
50
256
256
TTP-245 Plus
50
256
Depends on SD
card capacity
TDP-245
50
256
256
TDP-245 Plus
50
256
Depends on SD
card capacity
TTP-245G
50
256
256
TDP-245G
50
256
256
TTP-246M
50
256
256
TTP-246G
50
256
256
TTP-246M Plus
50
256
Depends on SD
card capacity
TTP-248M
50
256
256
TTP-2410M
50
256
Depends on SD
card capacity

TSC TTP-244CE series Specifications

General

Resolution	203 dpi
Processor	32-bit RISC CPU
Print Method	Thermal Transfer / Direct Thermal
Max Print Speed	4 inches per second
Memory	8 MB SDRAM, 4 MB Flash
Communication Interfaces	USB, Serial (RS-232)
Media Handling	Continuous, Fan-Fold
Media Type	Continuous, Die-cut, Black Mark, Fan-fold
Media Width	1 inch to 4.4 inches
Media Roll Diameter	127 mm (5 inches)
Ribbon Length	300 m
Ribbon Core	25.4 mm (1 inch)
Power	100-240 VAC, 50/60 Hz
Weight	2.5 kg
Max Print Length	2, 286 mm (90")
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D) 9.13" (W) x 6.14" (H) x 11.34" (D)
