 MAXICODE
Description
This command defines a 2D Maxicode.
Syntax
MAXICODE x, y, mode, [class, country, post, Lm,] "message"
For mode 2 or 3:
MAXICODE x, y, mode, class, country, postal code, “low priority message"
If country is 840, the postal code is in 99999,9999 format.
For other countries, the code is up to 6 alphanumeric characters.
For mode 4,5,6
MAXICODE x, y, mode, [Lm], "message"
* AIM special format is supported, see page 23 in the spec.
Note: Mode 6 is not supported in TSPL2 printers firmware.
Parameter Description
x X-coordinate of the starting point in dot
y Y-coordinate of the starting point in dot
mode 2,3,4,5
class Class of service, 3-digit number (for mode 2,3)
country Country code, 3-digit number (for mode 2,3)
post Post code (for mode 2,3)
Mode 2: (USA) 5-digit+ 4-digit number
Mode3: (Canada) 6 alphanumeric post code included by double
quotes.
Lm Expression length (double quote is ignored) , 1m138, (this
parameter is just for mode 4 and 5.)
message Barcode content
Example
SIZE 4,2
GAP 0,0
CLS
SPEED 4
DENSITY 8
OFFSET 0.00
REFERENCE 0,0
SET CUTTER OFF
SET TEAR ON
REM *****Mode 2 For USA*****

TSC TTP-244CE series Specifications

General

Resolution	203 dpi
Processor	32-bit RISC CPU
Print Method	Thermal Transfer / Direct Thermal
Max Print Speed	4 inches per second
Memory	8 MB SDRAM, 4 MB Flash
Communication Interfaces	USB, Serial (RS-232)
Media Handling	Continuous, Fan-Fold
Media Type	Continuous, Die-cut, Black Mark, Fan-fold
Media Width	1 inch to 4.4 inches
Media Roll Diameter	127 mm (5 inches)
Ribbon Length	300 m
Ribbon Core	25.4 mm (1 inch)
Power	100-240 VAC, 50/60 Hz
Weight	2.5 kg
Max Print Length	2, 286 mm (90")
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D) 9.13" (W) x 6.14" (H) x 11.34" (D)
