TSC TTP-244CE series User Manual

TSC AUTO ID Technology Co., Ltd. 13 Copyright 2009 All Rights Reserved.
 DENSITY
Description
This command sets the printing darkness.
Syntax
DENSITY n
Parameter Description
n 0~15
0: specifies the lightest level
15: specifies the darkest level
Note: Default DENSITY setting is 8
Example
DENSITY 7
See Also
DENSITY

TSC TTP-244CE series Specifications

General

Resolution	203 dpi
Processor	32-bit RISC CPU
Print Method	Thermal Transfer / Direct Thermal
Max Print Speed	4 inches per second
Memory	8 MB SDRAM, 4 MB Flash
Communication Interfaces	USB, Serial (RS-232)
Media Handling	Continuous, Fan-Fold
Media Type	Continuous, Die-cut, Black Mark, Fan-fold
Media Width	1 inch to 4.4 inches
Media Roll Diameter	127 mm (5 inches)
Ribbon Length	300 m
Ribbon Core	25.4 mm (1 inch)
Power	100-240 VAC, 50/60 Hz
Weight	2.5 kg
Max Print Length	2, 286 mm (90")
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D) 9.13" (W) x 6.14" (H) x 11.34" (D)
