TSC TTP-244CE series User Manual

TSC AUTO ID Technology Co., Ltd. 171 Copyright 2009 All Rights Reserved.
 KEY1, KEY2, KEY3
Description
This command reads the status of KEY1 ,KEY2 and KEY3.
Model
KEY0
KEY1
KEY2
KEY3
KEY4
KEY5
KEY6
TTP-243 series
PAUSE
FEED
TTP-243 Plus series
PAUSE
FEED
TTP-244ME series
PAUSE
FEED
TTP-244ME Plus series
PAUSE
FEED
TTP-244 series
PAUSE
FEED
TTP-244CE series
FEED
TTP-245 series
FEED
TTP-245C series
FEED
TDP-245 series
FEED
TTP-246M series*
MENU
PAUSE
FEED
(UP)
(DOWN)
(SELECT)
TTP-248M series
MENU
PAUSE
FEED
TTP-2410M series
MENU
PAUSE
FEED
UP
DOWN
SELECT
TDP-643 Plus
PAUSE
TDP-643R Plus
PAUSE
TTP-342 series
PAUSE
FEED
TTP-342 Plus series
PAUSE
FEED
TTP-342M series
PAUSE
FEED
TTP-342M Plus series
PAUSE
FEED
TTP-343 series
FEED
TTP-343C series
FEED
TTP-344M series
MENU
PAUSE
FEED
(UP)
(DOWN)
(SELECT)
TTP-346M series*
MENU
PAUSE
FEED
UP
DOWN
SELECT
TTP-384M series
MENU
PAUSE
FEED
UP
DOWN
SELECT
TTP-644M series
MENU
PAUSE
FEED
UP
DOWN
SELECT
M23 series
FEED
LEFT
MID
RIGHT
* For TTP-246M Plus and TTP-344M Plus, there are 6 button on the control panel.
Syntax
KEYm = n
Key Return Value
KEY1 (MENU) 0: released
1: pressed
KEY2 (PAUDE) 0: released
1: pressed
KEY3 (FEED) 0: released
1: pressed

TSC TTP-244CE series Specifications

General

Resolution	203 dpi
Processor	32-bit RISC CPU
Print Method	Thermal Transfer / Direct Thermal
Max Print Speed	4 inches per second
Memory	8 MB SDRAM, 4 MB Flash
Communication Interfaces	USB, Serial (RS-232)
Media Handling	Continuous, Fan-Fold
Media Type	Continuous, Die-cut, Black Mark, Fan-fold
Media Width	1 inch to 4.4 inches
Media Roll Diameter	127 mm (5 inches)
Ribbon Length	300 m
Ribbon Core	25.4 mm (1 inch)
Power	100-240 VAC, 50/60 Hz
Weight	2.5 kg
Max Print Length	2, 286 mm (90")
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D) 9.13" (W) x 6.14" (H) x 11.34" (D)
