Example

DOWNLOAD "DEMO.BAS"

SIZE 3,1

GAP 0,0

DENSITY 8

SPEED 3

DIRECTION 0

REFERENCE 0,0

SET CUTTER OFF

SET KEY1 OFF

SET KEY2 OFF

SET KEY3 OFF

KEY1=0

KEY2=0

KEY3=0

:START

IF KEY1=1 THEN

CLS

TEXT 100,10,"3",0,1,1,"KEY1 (MENU key) is pressed!! "

PRINT 1,1

ELSEIF KEY2=1 THEN

CLS

TEXT 100,10,"3",0,1,1,"KEY2 (PAUSE key) is pressed!!"

PRINT 1,1

ELSEIF KEY3=1 THEN

CLS

TEXT 100,10,"3",0,1,1,"KEY3 (FEED key) is pressed!!"

TEXT 100,60,"3",0,1,1,"End of test"

PRINT 1,1

SET KEY1 ON

SET KEY2 ON

SET KEY3 ON

END

ENDIF

GOTO START

EOP

DEMO

Questions and Answers:

Need help?

Do you have a question about the TSC TTP-244CE series and is the answer not in the manual?

TSC TTP-244CE series Specifications

General

Resolution	203 dpi
Processor	32-bit RISC CPU
Print Method	Thermal Transfer / Direct Thermal
Max Print Speed	4 inches per second
Memory	8 MB SDRAM, 4 MB Flash
Communication Interfaces	USB, Serial (RS-232)
Media Handling	Continuous, Fan-Fold
Media Type	Continuous, Die-cut, Black Mark, Fan-fold
Media Width	1 inch to 4.4 inches
Media Roll Diameter	127 mm (5 inches)
Ribbon Length	300 m
Ribbon Core	25.4 mm (1 inch)
Power	100-240 VAC, 50/60 Hz
Weight	2.5 kg
Max Print Length	2, 286 mm (90")
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D) 9.13" (W) x 6.14" (H) x 11.34" (D)
