TSC TTP-244CE series User Manual

TSC AUTO ID Technology Co., Ltd. 60 Copyright 2009 All Rights Reserved.
2). Alphanumeric data: 707 characters 4,296 characters
3). 8-bit byte data: 486 characters 2,953 characters
4). Kanji data: 299 characters 1,817 characters
*If "A" is the first character in the data string, then the following data after "A" is
Alphanumeric data.
*If "N" is the first character in the data string, then the following data after "N" is
numeric data.
*If "B" is the first character in the data string, then the following 4 digits after "B" is
used to specify numbers of data. After the 4 digits is the number of bytes of binary data
to be encoded.
*If "K" is the first character in the data string , then the following data after "K" is Kanji
data.
*If "!" is in the data string and follows by "N", "A", "B", "K" then it will be switched to
specified encodable character set.
Model
QR Code
TTP-243 series
TTP-243 Plus series
X
TTP-244ME series
TTP-244ME Plus series
X
TTP-244 series
X
TTP-244CE series
X
TTP-245 series
X
TTP-245C series
X
TDP-245 series
X
TTP-246M series
X
TTP-248M series
TTP-2410M series
X
TDP-643 Plus
TDP-643R Plus
X
TTP-342 series
TTP-342 Plus series
X
TTP-342M series
TTP-342M Plus series
X
TTP-343 series
X
TTP-343C series
X
TTP-344M series
X
TTP-346M series
X
TTP-384M series
X
TTP-644M series
X
M23 series
X

TSC TTP-244CE series Specifications

General

Resolution	203 dpi
Processor	32-bit RISC CPU
Print Method	Thermal Transfer / Direct Thermal
Max Print Speed	4 inches per second
Memory	8 MB SDRAM, 4 MB Flash
Communication Interfaces	USB, Serial (RS-232)
Media Handling	Continuous, Fan-Fold
Media Type	Continuous, Die-cut, Black Mark, Fan-fold
Media Width	1 inch to 4.4 inches
Media Roll Diameter	127 mm (5 inches)
Ribbon Length	300 m
Ribbon Core	25.4 mm (1 inch)
Power	100-240 VAC, 50/60 Hz
Weight	2.5 kg
Max Print Length	2, 286 mm (90")
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D) 9.13" (W) x 6.14" (H) x 11.34" (D)
