TSC TTP-244CE series User Manual

TSC AUTO ID Technology Co., Ltd. 62 Copyright 2009 All Rights Reserved.
ABC<Enter>
abc"
QRCODE 310,310,H,4,A,0,"印表機<Enter>
ABC<Enter>
abc<Enter>
123"
PRINT 1,1
c. Data string concatenation (Must be used with DOWNLOAD ... EOP command)
DOWNLOAD “DEMO.BAS”
SIZE 4,2.5
CAP 0.12,0
CLS
QRCODE 10,10,H,4,A,0,"ABCabc123"+STR$(1234)
QRCODE 160,160,H,4,A,0,"123ABCabc"+"1234"
QRCODE 310,310,H,4,A,0,"印表機 ABCabc123"+"1234"+"abcd"
PRINT 1,1
EOP
DEMO
d. Data string including double quote (“) character, please use \["] instead of
SIZE 4,2.5
CAP 0.12,0
CLS
QRCODE 10,10,H,4,A,0,"ABC\["]abc\["]123"
QRCODE 160,160,H,4,A,0,"123\["]ABC\["]abc"
QRCODE 310,310,H,4,A,0,"\["]印表機\["]ABCabc123"
PRINT 1,1
(3) Manual mode
a. General data string：
SIZE 4,2.5
CAP 0.12,0
CLS
QRCODE 10,10,H,4,M,0,"AABC!B0003abc!N123"
QRCODE 160,160,H,4,M,0,"N123!AABC!B0003abc"
QRCODE 310,310,H,4,M,0,"K 印表機!AABC!B0006abc123"
PRINT 1,1
b. Data string including <Enter> character, <Enter> is an 8-bit byte data
SIZE 4,2.5
CAP 0.12,0
CLS
QRCODE 10,10,H,4,M,0,"AABC!B0007<Enter>
abc<Enter>
!N123"
QRCODE 160,160,H,4,M,0,"N123!B0002<Enter>
!AABC!B0005<Enter>
abc"

TSC TTP-244CE series Specifications

General

Resolution	203 dpi
Processor	32-bit RISC CPU
Print Method	Thermal Transfer / Direct Thermal
Max Print Speed	4 inches per second
Memory	8 MB SDRAM, 4 MB Flash
Communication Interfaces	USB, Serial (RS-232)
Media Handling	Continuous, Fan-Fold
Media Type	Continuous, Die-cut, Black Mark, Fan-fold
Media Width	1 inch to 4.4 inches
Media Roll Diameter	127 mm (5 inches)
Ribbon Length	300 m
Ribbon Core	25.4 mm (1 inch)
Power	100-240 VAC, 50/60 Hz
Weight	2.5 kg
Max Print Length	2, 286 mm (90")
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D) 9.13" (W) x 6.14" (H) x 11.34" (D)
