TurboChef i3 Service Manual

A-6 APPENDIX - REPLACING OVEN COMPONENTS
Figure
Reference #
Item Description Item Part Number Hardware Description Hardware Part Number(s)
1 Capacitor, High-Voltage (x2) 100232 None None
2 Capacitor, Magnetron Fan 100242
A) Washer, Split Lock, 3/8
B) Nut, Hex, M8, Cres
A) 102340
B) 101057
3 Capacitor Clamps (x2) 100134 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 2) each
4 Control Board CON-3001 Nut, Keps, Hex, #6-32, Ext Tooth, Cres 102961 (qty 4)
5 Cooling Fan, Exterior (x2) TC3-0433 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 2) each
6 Cooling Fan, Interior 100516 Screw, #8-32 x 2” Lg, PPHD, SS 101659 (qty 2)
7 Cooling Fan Finger Guard (x2) 100086 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 2) each
8 Cooling Fan, Magnetron 100091 Screw, M4 x 6, PPH SQ CO Sems, Zinc 101672 (qty 4)
9 Cooling Fan Ring, Magnetron 100092 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 4)
10 Diode, High-Voltage (x2) 100481 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 2) each
11 Display, TFT i5-3207 Nut, Keps, Hex, #4-40, Ext Tooth 102960 (qty 4)
12 Magnetron (Left) NGC-3015 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 4)
13 Magnetron (Right) NGC-3015 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 4)
14 Motor Controller 100446 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 4)
15 Smart Card/USB Port CON-7005
A) Standoff, Round, .12 ID, .25 OD x .375”
B) Nut, Keps, Hex, #4-40, Ext Tooth
A) 101923 (qty 4)
B) 102960 (qty 4)
16 Stirrer Coupling Spider Insert 104134 None None
17 Stirrer Hub (x2) 104132 Set Screw (Provided) N/A
18 Stirrer Motor 100884 Screw, M4 x 6, PPH SQ CO Sems, Zinc 101672 (qty 2)
19 Stirrer Motor Bracket i5-9075 Screw, M4 x 6, PPH SQ CO Sems, Zinc 101672 (qty 2)
20 Stirrer Shaft* i5-9151 / i3-9151* None None
21 Stirrer Shaft, Support i5-9152 None None
22 Thermostat, Magnetron (Left) 102070 Screw, Sh Mtl, Drill Point, 6-32 x 3/8, PPHD, Zinc 101684 (qty 2)
23 Thermostat, Magnetron (Right) 102070 Screw, Sh Mtl, Drill Point, 6-32 x 3/8, PPHD, Zinc 101684 (qty 2)
24 Transformer, Filament (x2) NGC-3061-1 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 4) each
25 Transformer, High-Voltage (x2) NGC-3062-1 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 4) each
N/A Waveguide (Left) i5-3210 Nut, Keps, Hex, #10-32, Ext Tooth, Cres 102963 (qty 9)
N/A Waveguide (Right) i5-3210 Nut, Keps, Hex, #10-32, Ext Tooth, Cres 102963 (qty 9)
N/A Waveguide Gasket (Left) i5-9331 None None
N/A Waveguide Gasket (Right) i5-9331 None None
* The i3 utilizes two versions of the stirrer shaft. Ovens with serial numbers between 00001 and 01000
must use i5-9151. All i3 ovens with a serial number of 01001 or greater use i3-9151.

TurboChef i3 Specifications

General

Model	i3
Cooking Chamber	Stainless Steel
Cavity Dimensions	14.5 x 16 x 10 inches
Power Requirements	208-240V, 30A
Control Type	Touchscreen
