A-4 APPENDIX - REPLACING OVEN COMPONENTS
Opening Top Cover Required (Figure A-3)
CAUTION: Before removing/installing any component, make sure it is disconnected from the
wire harness (where applicable).
NOTE: Hardware listed is required for installing component to oven.
To open the top cover:
1. Open the oven door.
2. Remove the two screws that secure the top cover to the heat shield (above the oven door).
3. Open the top cover.
4. Secure the support arm in place.
Figure
Reference #
Item Description Item Part Number Hardware Description Hardware Part Number(s)
1 Capacitor and Diode, Monitor Relay
i5-9390 None None
N/A Cover, Top i3-9243 Screw, #10-32 x 3/8 lg, PFLH, 100 Deg, SS 101401 (qty 2)
2 Fuse, F1, 12-amp 100592 None None
3 Fuse, F2, 12-amp 100592 None None
4 Fuse, F3, 20-amp 100599 None None
5 Fuse Holder 103566 Screw, #8-32 x 3/8, PPHD, Int Sems, SS 102921 (qty 4)
N/A Heat Shield/Support Bracket* i3-9224 Screw, Torx Head, Sh Mtl, 3/8, Cres 102752 (qty 2)
N/A Keypad* i3-9247 None None
6 Power Supply 101211 Screw, M3 x 8mm, Sems, PPHD, Cres 103444 (qty 3)
7 Relay (K1 - Filament) 101274 Nut, Keps, Hex, #6-32, Ext Tooth, Cres 102961 (qty 2)
8 Relay (K2 - Anode) 101273 Nut, Keps, Hex, #6-32, Ext Tooth, Cres 102961 (qty 2)
9 Relay (K3 - Monitor) 101273 Nut, Keps, Hex, #6-32, Ext Tooth, Cres 102961 (qty 2)
10 Relay (K6 - Voltage) 101272 Nut, Keps, Hex, #6-32, Ext Tooth, Cres 102961 (qty 2)
11 Relay (K7 - Mag Fan) 101274 Nut, Keps, Hex, #6-32, Ext Tooth, Cres 102961 (qty 2)
12 Relay (K8 - Stirrer) 101274 Nut, Keps, Hex, #6-32, Ext Tooth, Cres 102961 (qty 2)
13 Relay, Solid State (K4/K5 - Heaters) 101286 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 2)
N/A Thermostat, Cooling Fans* 102086 Screw, #6 x 1/2, PPHD, Drill Point, SS 101687 (qty 2)
14 Voltage Sensor 100783 Screw, Sh Mtl #8 x 1/2, Serrated PHTRH 101688 (qty 1)
* Detail on page A-7.
