A-8
APPENDIX - REPLACING OVEN COMPONENTS
Figure
Reference #
Item Description Item Part Number Hardware Description Hardware Part Number(s)
1 Blower Motor (top) i5-9220 Nut, 1/4 - 20, Serr Hex Flange, Plated 100906 (qty 4)
2 Blower Motor (bottom) i5-9221 Nut, 1/4 - 20, Serr Hex Flange, Plated 100906 (qty 4)
3 Blower Wheel (top) 104107 None None
4 Blower Wheel (bottom) 104108 None None
N/A Cover, Left Side i3-9301 Screw, #8 Serr, PHD Truss, Black Oxide 101691 (qty 5)
5 Heat Slinger 102708 None None
6 Helper Spring, Interlock Switch* i5-9397 None None
7 Interlock Switch, Primary* 102012 Screw, #4-40 x 1”, PPH, Sems 102903 (qty 2)
8 Mounting Bracket, Interlock Switch* i5-9272 Screw, #10-32 x 3/4 lg, PPH Sems, Int Th 102937 (qty 2)
N/A Power Cord i5-9127 None None
Removing Left Side Cover Required (Figures A-7, A-8)
CAUTION: Before removing/installing any component, make sure it is disconnected from the
wire harness (where applicable).
CAUTION: Be careful to not tear the insulation when servicing components. Always reset the
insulation properly before reinstalling the side panel.
Hardware listed is required for installing component to oven.
To remove the left side cover, remove the screws securing the panel to the oven frame. To re-install the left
side cover, you may need to open the top cover (see page A-4 for details).
* NOTE: For more interlock switch detail, see Figure A-10, page A-11.
