TurboChef Sota

APPENDIX  REPLACING OVEN COMPONENTS
A3
Figure
Reference #
Item Description Item Part Number Fastener Description Fastener Part Number(s)
1 Actuator, Door Latch NGC-1076-2 Screw, Torx w/ Post, Sht Mtl, .50 Lg, Blk Ox 102756 (qty 2)
2
Bracket, Removable, Filter-
Catalyst
i1-9559 (DARDEN only)
3 Cover, Outer Shell
i1-3230-1-T004 (SOTA)
i1-3230-1-T002 (SBK)
i1-9530-2-T008 (STAINLESS)
i1-3230-1-T3020 (PANINI)
Screw, #8 x 1/2, Serr Ph Truss Hd, Bk Oxide
Screw, #8 x 1/2, Security, Torx Hd, Bk Oxide
101691 (qty 6)
102756 (qty 2)
4 Door, Complete Assembly
i1-3201-1 (SOTA)
i1-3201-2 (SBK)
i1-3201-3 (PANINI)
i1-3201-5 (STAINLESS)
Included Included
5 Door Handle
i1-9459 (SOTA/SBK/PANINI)
i1-9537 (STAINLESS)
Screw, Skt Hd Button, 3/8-16 X 1.00 LG, SS
Washer, 3/8, Flat, SS
Nut, Keps, 3/8-16, Stl
i1-9178 (qty 2)
102210 (qty 2)
102964 (qty 2)
6 Door Skin
i1-9528-1-T004 (SOTA)
i1-9528-2-T002 (SBK)
i1-9528-3-T008 (STAINLESS)
Screw, #8 x 3/8, Ph Mod Truss Head, Black
Oxide, Cres
101372 (qty 15)
7 Filter, Air, Intake i1-9039 None None
8 Filter Bracket, Intake
i1-9531-T004 (SOTA)
i1-9531-T002 (SBK)
i1-9045 (STAINLESS)
i1-9531-3020 (PANINI)
Screw, #8 x 1/2, Serr Ph Truss Hd, Sheet Mtl 101688 (qty 8)
9 Filter, Cavity
i1-9569 (SOTA)
i1-9557 (STAINLESS)
10 Jetplate (Bottom), with Diverter
i1-9159-1 (SOTA/SBK)
i1-9159-2 (STAINLESS)
None None
11 Kit, Door Shunt Plate
i1-3210 (SOTA/SBK)
i1-3210-2 (STAINLESS)
Included Included
12 Kit, Jetplate (Top) i1-3219 None None
13 Kit, MW Stirrer i1-3212 Included Included
14 Leg (x4)
HHB-3205 (SOTA)
100781 (SBK)
None None
15 Letter, S (SOTA only) i1-9052 (SOTA only) Nut, Push, .094” 104307 (qty 3)
16 Letter, O (SOTA only) i1-9053 (SOTA only) Nut, Push, .094” 104307 (qty 2)
17 Letter, T (SOTA only) i1-9054 (SOTA only) Nut, Push, .094” 104307 (qty 2)
18 Letter, A (SOTA only) i1-9055 (SOTA only) Nut, Push, .094” 104307 (qty 2)
19 Letter, Caret (SOTA only) i1-9056 (SOTA only) Nut, Push, .062” 104308 (qty 1)
20 Lower Front Panel
i1-9529-T004 (SOTA)
i1-9529-T002 (SBK)
i1-9573 (STAINLESS)
Ball Stud, Male, #6-32x.447” Lg (SOTA/SBK)
Washer, Split Lock (SOTA/SBK)
Ball Stud (DARDEN)
100027 (qty 3)
102380 (qty 3)
HHB-8189 (qty 2)
21 Pad, Abrasive, Non-Slip (x4) NGC-1187 None None
22 Rack, Standard i1-9398 None None
23 Rail, Support, Top Jetplate (x2)
i1-9179-2 (also included
with i1-3219 kit)
Screw, #8 x 1/2, Serr Ph Truss Hd, Sheet Mtl 101688 (qty 2 per)
24 Vent Catalyst Foil Pack RWD-9191 None None
25 Vent Tube Cover NGC-1392 Screw, #6 x 1/2, PPHD, Drill Point, SS 101687 (qty 2)
26
Weldment, Heat Channel,
Vent Tube
NGC-1397 Screw, #8 x 1/2, Serr Ph Truss Hd, Sheet Mtl 101688 (qty 6)
Optional Stone, Baking, Fibrament i1-9533 None None
Optional Kit, Panini Grill and Rack i1-3221 None None
