Troubleshooting:
F6: EC TEMP (Electrical Compartment Temperature High)
YES
NO
Does the oven have
room to ventilate?
Required clearances:
Top: 5” (127 mm)
Sides: 2” (51 mm)
Is the oven in an area of moderate
temperature (120ºF [49ºC] or cooler)?
YES
Are five of the seven
cooling fans rotating?
(The other two side
fans are enabled only
when the microwave
circuit is on.)
NO
Relocate oven to
cooler area.
YES
Check for obstructions in
the airflow and remove
them and clean the filter.
YES
Replace defective
component.
Troubleshooting:
F7: THERMO (RTD Open)
YES
NO
Is the RTD properly connected to the
control board? (See page 79 for
schematic.)
NO
Correct wiring.
YES
NO
Correct connection.
Is the wire harness properly
connected? Check cooling
fan thermostat and cooling fans.
(See page 79 for schematic.)
Move oven to open area or remove
items that are in close proximity.
Is the RTD open?
Using an Ohmmeter,
measure at the A7 and
A9 terminals on the
control board. RTD
should measure approxi-
mately 109 Ohms at
75
ºF (24ºC)
. Use Figure
39, page 53 to deter-
mine resistance readings
at other temperatures.
Replace the I/O Control
Board (SAGE).
Replace the RTD.
