MX/MZX
17A-04-S
17 10/09
PAGE 30 of 40
‘>>’ - copies the ‘old text’ to the ‘New text’ position.
‘-’ moves the cursor back one position.
‘+’ moves the cursor forward one position.
Modify the old text or insert new text using the
alphanumeric keypad, when finished press Enter.
Pressing the scroll up key allows text to be entered in
upper case.
Pressing the scroll down key changes to lower case
text.
The message ‘Save Data?’ appears and the functions change
F4 to ‘Yes’ and F5 to ‘No’. Selecting F5 allows the text
modifications to be changed.
Selecting F4 ‘Yes’ displays the message:
Please wait.....
then the following screen is displayed:
It is now possible to change the text for another Point.
Selecting F1 ‘Back’ will display the following screen:
Only ‘Change Text’ and ‘Restart’ are available allowing
more points to be changed or using ‘Restart’ to allow the
changes to take effect.
MX Panel
Wed, 01-Mar-08
14:15
Company Name
General
Back
Change Text
1 - Point Text
MX Panel
Wed, 01-Mar-08
14:15
Company Name
General
Back
Configuration
1 - Change Text
9 - Restart
3.14.1.2 ZONE TEXT MODIFY
Press 2 from the Configuration menu. The following screen
will be displayed:
Select the required and press Enter. The following type of
screen will be displayed:
‘>>’ - copies the ‘old text’ to the ‘New text’ position.
‘-’ moves the cursor back one position.
‘+’ moves the cursor forward one position.
Modify the old text or insert new text using the
alphanumeric keypad, when finished press Enter.
The message ‘Save Data?’ appears and the function change
F4 to ‘Yes’ and F5 to ‘No’. Selecting F5 allows the text
modifications to be changed.
Selecting F4 ‘Yes’ displays the message:
Please wait.....
then the following screen is displayed:
MX Panel
Wed, 01-Mar-08
14:15
Company Name
General
Back
Zone Text Modify
Zone : 001
-
+ Enter
MX Panel
Wed, 01-Mar-08
14:15
Company Name
General
Back
Zone Text Modify
Zone : 001
Old text
Zone 01
New text
>>
-
+ Enter
To Next Page
