TYM T390 Service Manual

9-7
(Fig.9-10).Apply grease to the roll bush.
Fig.9-10
7) Drive the oil seal onto the lift shaft and install
the lift arm.
Note:
When installing the oil seal,take care not to
allow the oil seal lips to be damaged by the
splines of the lift shaft.
8) Install the cylinder and piston.Then install
the cylinder head.

TYM T390 Specifications

General

Brand	TYM
Model	T390
Category	Tractor
Language	English
