Doc No. FM0804 issue 4 Page 15
10. NETWORK TERMINATION BOARD
FUSES
There is fuse protection on the 24V DC and 12V DC supply on each of the 3 Network leg connections. The LED
alongside each fuse will extinguish if a fuse is blown.
Fuse No.
Rating
Function
LED
F1
1.6A
24V Network 1
LED 3
F2
1.6A
12V Network 1
LED 4
F3
1.6A
24V Network 2
LED 5
F4
1.6A
12V Network 2
LED 6
F5
1.6A
24V Network 3
LED 7
F6
1.6A
12V Network 3
LED 8
Remember CW1308 cable is only rated at 0.25A per core, or 0.5A if a pair is used for power.
