UFactory xArm6 - DC Control Box Connector Definition

UFactory xArm6
184 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
32
2.2.2. Definition of Industrial Connector
4-Pin Industrial Connector (External 24V Power )
Industrial connector wire sequence
Functional definition
1
24V
2
GND
3
Null
4
Null
