Ulvac PMB100D - Page 45

YK11-0016-DI-002-08
18
Fig. 16 Pumping speed curves - MODEL PMB100D/300D/600D(Standard)
Fig. 17 Pumping speed curves - MODEL PMB1200D/2400D(Standard)
0
100
200
300
400
500
600
700
0.1 1 10 100 1000 10000 100000
Pumping Speed (m3/h)
Pressure (Pa)
PMB300(60Hz)+VD60(60Hz)
PMB300(50Hz)+VD60(50Hz)
PMB600(50Hz)+VD90(50Hz)
PMB100(50Hz)+VD40(50Hz)
PMB600(60Hz)+VD90(60Hz)
PMB100(60Hz)+VD40(60Hz)
0
500
1000
1500
2000
2500
3000
0.1 1 10 100 1000 10000 100000
Pumping Speed (m3/h)
Pressure (Pa)
PMB1200(60Hz)+VS2401(60Hz)
PMB2400(50Hz)+PKS-070(50Hz)
PMB1200(50Hz)+VS2401(50Hz)
PMB2400(60Hz)+PKS-070(60Hz)
