YK11-0016-DI-002-08
25
3. Mounting
WARNING
You are requested to
install and operate the product in compliance
with the laws and regulations relating to the safety, e.g. Fire Defense
Law, Electric wiring regulation and so on in the country and region
you use the product. Consequently you shall be requested to attend
gen
eral safety lectures officially effective in the area, such as
electrical safety, Cargo handling safety and so on. Note that any
person not attended such lectures shall be restricted from handling
the product. Operators shall need to attend such kind of tr
have special knowledge, skill and title regarding the electricity,
machinery, cargo, vacuum and so on.
Be sure to clear any energy sources, e.g. electricity, coolant and so
on of the product before installing or removing the product.
3.1 Storage/ Installation
Install the machine horizontal to a place where there are less dust and humidity.
Fix the pump horizontally so that there is not a wobble.
Make a layout taking into consideration of works such as setting, removal, check, cleaning and so
on.
Refer to “0.5 3 Acceptance and Storage of The Pump” as for the detail.
Fix the pump to the rack with bolts at four places.
CAUTION
Operating the pump on laying it down or putting it reverse would
give damage to the pump. Ensure to install the pump horizontal to
the ground level as illustrated on the “Fig. 8 to Fig. 12”.
By the form of the rack, the pump may cause resonance, and their
vibration may become big.
On this case, sandwich the protection against vibration rubber
between a pump and rack.
To Next Page
