Uniden BCD436HP Owner's Manual

19
KEYPAD AND KNOB CONTROLS
BCD536HP
Key Operation
Power/VOL Light • Turns the scanner on/o and adjusts the volume.
• Press Func then Vol to view P25 Adjustment mode.
• Press to toggle backlight intensity.
SQ
• Turn to adjust the squelch.
• Press to toggle Close Call modes.
• Press and hold to enable Close Call Only mode.
• Press Func then SQ to start Fire Tone-Out Standby Search.
Scroll Control/Function • Press to enter Function mode for 3 seconds.
• Press to select a menu item or save an entry in Menu mode.
• Turn to select a menu item in Menu mode.
• Turn to set decode threshold in P25 Adjustment mode.
• Turn to select characters with Data Naming.
• Turn to select Scan/Search direction and to continue Scan/Search in
Scan/Search modes.
• Turn to scroll Channels or Frequencies in Hold modes.
• Turn in Department Pause to scroll Departments.
• Turn in System Pause to scroll Systems.
• Turn in Site Pause to scroll Site in current system.
• Turn in Search Pause to select Custom Search Banks to enable in Search
mode.
• Turn to select next or previous recording in Replay mode.
• Turn to resume Close Call search in Close Call mode.
• Turn to start a Quick Search Hold mode in Close Call Hold mode.
• Turn to select next Weather Channel in Weather Scan.
• Turn to select Tone-outs in Tone-out Standby/Search mode.
• Press Func then Avoid to review avoids in the current system in Scan
mode.

Uniden BCD436HP Specifications

General

Model	BCD436HP
Antenna	Removable SMA Antenna
Close Call RF Capture	Yes
Dynamic Memory	Yes
PC Programmable	Yes
Water Resistance	No
Category	Scanner Radio
Display	Dot-matrix LCD
Power Source	3x AA batteries or USB power
Weight	10.1 oz
Type	Handheld
GPS	Optional GPS receiver supported
Audio Output	Earphone jack (3.5 mm)
Trunking Systems Supported	Motorola, EDACS, LTR, APCO 25 Phase I and Phase II
Modulation Types	AM, FM, NFM, P25
Battery Life	Varies with usage
Display Type	LCD
USB Port	Yes
SD Card Slot	Yes
Frequency Range	25-512 MHz, 758-960 MHz, 1240-1300 MHz
