Uniden BCD436HP Owner's Manual

88
TECHNICAL SPECIFICATIONS  BCD436HP
Band Coverage : 31 Bands
Size: 2.8 in (W) x 1.5 in (D) x 6.3 in (H) (without antenna)
71.1 mm (W) x 36.9 mm (D) x 160.9 mm (H) (without antenna)
Weight: 12.3 oz. (with antenna and battery)
Operating Temperature: + 14º F (– 10º C) to + 140º F (+ 60º C )
Storage Temperature: – 22º F (– 30º C) to + 158º F (+ 70º C )
Power Requirements: 3 X AA Rechargeable Ni-MH Batteries (2300mAh) (included)
3 X AA Alkaline Batteries (not included)
DV 5.0V ±5%. Connect to PC with USB cable (included)
LCD Display: 192 X 160 Full Dot Matrix LCD with white-color backlight.
Internal Speaker: 24ohm, 0.8W Max.
Certied in accordance with FCC Rules and Regulations Part 15 Sub-part C as of date of
manufacture.
Weather Channels: 7 Channels
Scan Rate: 85 channels/second
Search Rate: 80 steps/second (12.5kHz step)
250 steps/second (5kHz step)
Scan Delay: 2 seconds
Audio Output Power: Internal Speaker - 360mW nominal
(24ohm)
Headphone (L-ch) 4mW nominal
(32 ohm)
Antenna: 50 ohms (Impedance)
Sensitivity (12dB SINAD) Nominal
VHF Low 1 Band
(AM) 25.005 MHz 0.4 μV
(NFM) 40.840 MHz 0.3 μV
(NFM) 53.980 MHz 0.3 μV
VHF Low 2 Band
(WFM) 54.050 MHz 0.7 μV
(FM) 72.515 MHz 0.3 μV
(FMB) 107.100 MHz 0.6 μV
Aircraft Band
(AM) 118.800 MHz 0.4 μV
(AM) 127.175 MHz 0.4 μV
(AM) 135.500 MHz 0.4 μV

Uniden BCD436HP Specifications

General

Model	BCD436HP
Antenna	Removable SMA Antenna
Close Call RF Capture	Yes
Dynamic Memory	Yes
PC Programmable	Yes
Water Resistance	No
Category	Scanner Radio
Display	Dot-matrix LCD
Power Source	3x AA batteries or USB power
Weight	10.1 oz
Type	Handheld
GPS	Optional GPS receiver supported
Audio Output	Earphone jack (3.5 mm)
Trunking Systems Supported	Motorola, EDACS, LTR, APCO 25 Phase I and Phase II
Modulation Types	AM, FM, NFM, P25
Battery Life	Varies with usage
Display Type	LCD
USB Port	Yes
SD Card Slot	Yes
Frequency Range	25-512 MHz, 758-960 MHz, 1240-1300 MHz
