Uniden BCD436HP Owner's Manual

27
10 sec - Turns the backlight on for 10 seconds when you press .
30 sec - Turns the backlight on for 30 seconds when you press
.
60 sec - Turns the backlight on for 30 seconds when you press
.
Infinite - The backlight always stays on.
Set Dimmer (BCD436HP Only)
High, Middle, or Low
Set Dimmer (BCD536HP Only)
Manual (For non-vehicle use) - High, Middle, Low, or Off.
Note: You can also toggle the backlight brightness by pressing Vol.
Auto (For vehicle use)
+ Polarity - If the orange wire gets 12V when you turn on the headlights.
- Polarity - If the orange wire is switched to chassis ground when you turn on the
headlights.
Adjust Contrast – This setting controls the displays contrast.
Contrast 1-15
Display Unit ID – Allows you view the unit ID of the radio currently transmitting on Motorola,
EDACS, and APCO P25 systems.
On or Off
Set ID Format – Sets the ID display format for the System.
Set ID Format (Mot/P25)
Decimal Format or Hex Format. The default setting is Decimal.
Set ID Format (EDACS)
AFS Format or Decimal Format. The default setting is AFS.
Set Upside-Down (BCD536HP Only) – This allows you to reverse the display so you can mount
the scanner upside-down and hear the speaker from the top. The default setting is Off.
On or Off
Selecting 3-Line Display Mode
Hold on any channel and press Func then 9(DISP). Press Channel to resume.
3-Line Display O

Uniden BCD436HP Specifications

General

Model	BCD436HP
Antenna	Removable SMA Antenna
Close Call RF Capture	Yes
Dynamic Memory	Yes
PC Programmable	Yes
Water Resistance	No
Category	Scanner Radio
Display	Dot-matrix LCD
Power Source	3x AA batteries or USB power
Weight	10.1 oz
Type	Handheld
GPS	Optional GPS receiver supported
Audio Output	Earphone jack (3.5 mm)
Trunking Systems Supported	Motorola, EDACS, LTR, APCO 25 Phase I and Phase II
Modulation Types	AM, FM, NFM, P25
Battery Life	Varies with usage
Display Type	LCD
USB Port	Yes
SD Card Slot	Yes
Frequency Range	25-512 MHz, 758-960 MHz, 1240-1300 MHz
