6.WEIGHING MODE SETTING AND OPERATION
85
＜ Example ＞ AZ times is set to “03”
At start NZ confirmation
You can enable/disable Near zero check at the start of weighing sequence. The
weighing sequence can start if Near zero is ON, and it is inhibited to start if the
bit is “0”, generating “Sequence Error 4”.
For furthre information on Near zero settings, see Section 6-5. "Near Zero /
Upper Limit / Lower Limit" , page79.
At start WV confirmation
You can enable/disable the F159 to check if the weight is equal or larger than SP1
point (Final – SP1 set value).
“Sequence Error 5” is generated if the initial weight is equal or larger then SP1
point.
For furthre information on SP1 settings, see Section 6-4. "Final / Set Point 2 / Set
Point 1 / FF CPS. / Over / Under" , page78.
Start
Auto Zero
AZ times
3 times
・Auto Zero is executed when the Start signal turns ON.
・Auto Zero is executed when the Start signal turns ON.
・Disabling Auto Zero “00” does not inhibit Tare subtraction and Digital
Zero operation.
To Next Page
