Example) Switch the hold/judge ON (address 00001) to digital zero reset (address 00004)
ON/OFF.
Keep in mind that the relative address for writing in the hold/judge ON is 0x00.
The example shows rewriting of the F331 ON (1)/OFF (0) as follows:
Fill unused bits with "0".
* To judge coil execution, judge as complete with a normal response.
* Due to the nature of the commands, simultaneous execution in combination with the
following addresses should be avoided.
In this case, sequential execution results but correct operation may not be performed.
- Addresses 00001 and 00002
- Addresses 00003 and 00004
- Addresses from 00005 to 00007
16 (0x10) Write multiple registers
On slave holding registers, data is changed by the specified number from the specified address.
If broadcast (0) is specified, all slave holding registers of the same address are rewritten.
To request, specify the register address and the number of registers and data to change.
The slave transmits the contents of one register as expanded in double bytes.
* N = Number of registers
[Request]
Function 0F
[Response]
Function 0F
Start address; higher 00 Start address; higher 00
Start address; lower 00 Start address; lower 00
Number of coils; higher 00 Number of coils; higher 00
Number of coils; lower 04 Number of coils; lower 04
Number of data bytes 01
(Hold/judge ON -
digital zero reset)
05
Coil 00008 00007 00006 00005 Digital
zero
reset
Digital
zero
Hold/
judge
OFF
Hold/
judge
ON
Bit 00000101
[Request]
Function 1 byte 0x10
Start address 2
bytes 0x0000 - 0xFFFF
Number of registers 2
bytes 0x0001 - 0x0078 (120)
Number of bytes 1
byte 2×N *
Change data N×2 bytes
[Response]
Function 1 byte 0x10
Start address 2 bytes 0x0000 - 0xFFFF
Number of registers 2
bytes 0x0001 - 0x007B (123)
[Error response]
Error code 1 byte 0x90 (function + 0x80)
Exception code 1 byte 01 or 02 or 03
