Data type Address Data name
Setting
LOCK
Calibration
LOCK
Data format
Coil
0XXXX
00001 Hold/judge ON
B1
00002 Hold/judge OFF
00003 Digital zero
00004 Digital zero reset
00005 Zero calibration
○
00006 Actual load calibration
○
00007 Equivalent input calibration
○
00008 Reserve (no assignments)
Input status
1XXXX
10001 +LOAD, -LOAD
B1
10002 OFL1, OFL2
10003 HH
10004 HI
10005 OK
10006 LO
10007 LL
10008 NZ
10009 Under a hold/ under a judgment
10010 Setting value LOCK
10011 Calibration value LOCK
10012
Reserve (no assignments)
－
10016
Input register
3XXXX
30001 Status 1
I16
30002 Status 2
30003 Status 3
30004 Linked with indicated value
30005 Not linked with indicated value
30006
Reserve (no assignments)
－
30010
Holding register
4XXXX
40001 HH limit
○
I16
40002 HI limit
○
40003 LO limit
○
40004 LL limit
○
40005 Hysteresis
○
40006 Digital offset
○
40007 Near zero
○
40008 Comparison timing
○
40009 Moving average filter
○
40010 Digital low-pass filter
○
40011 Decimal place
○
40012 ZERO key valid/invalid
○
40013 Hold mode
○
40014 Display frequency
○
40015 External output selection
○
40016 Setting value LOCK
40017 Calibration value LOCK
40018 Actual load calibration (capacity)
○
40019 Equivalent input calibration (rated output)
○
40020 Zero calibration (read only)
○
40021
Reserve (no assignments)
－
40032
