4 & 8 & 16 Channel DVR Operation manual Revision 1.0
Description:
1. CD-RW/DVD-RW
z Easy backup by CD-RW/DVD-RW is available. The cover of CD-RW/DVD-RW shows an
excellent design.
2. Playback
z RECORD: Press once to begin recording all active channels. Press again to end recording.
z R-PLAY: Reverse Playback. Press to begin reverse playback. Under PTZ control menu,
used to decrease the speed of Pan, Tilt, Zoom, Focus.
z STOP: Stop playback.
z PLAY: Access to playback.
- Playback button will activate assigned starting position and Channel at playback setup of
menu.
- At pause mode, it will release pause mode.
- Under PTZ control menu, used to increase the speed of Pan, Tilt, Zoom, Focus.
z PAUSE : Press once to freeze playback. Press again to restart playback.
3. LED Display
z POWER : During Standby mode, red light on, during running unit, green light on
z REC : During recording green light flashes
4. Function Button
z POWER: Press this button to power ON/OFF
- Soft Power method is adapted. Therefore, If Power button is pressed,
user is asked to input Password, before Power off.
z LOCK: Press this button to lock/unlock the buttons of DVR, in order to prevent the use by
Unapproved user.
- If the LOCK button is pressed, DVR is locked, and it’s unlocked by inputting correct
password
z ZOOM: Zoom In/Out on the images during Live Viewing.
z FRZ : Freeze.
- Press button once to freeze the frame at live mode. Press again to return.
- To take a still image capture at playback mode.
- Exchange of video input type : Press power button with FRZ button from NTSC to Pal
or PAL to NTSC.
z MISC/SH: Miscellaneous functions or Shuttle Hold.
- MISC: To substitute for the buttons that are placed on the remote control but that are
not placed on the keypad (NET, OSD, Audio Mute, HDD, LOG).
(If the button is pressed, windows appear, and user can select lower menu one by one)
