18
4 & 8 & 16 Channel DVR Operation manual Revision 1.0
If you double click “SEQ” , it views 4 screen divisions.
This button also can be used for all motions area release purpose on motion detection
set up menu.
5. Numeric button - Live Viewing mode button
z 16ch DVR : 1, 2, 3, 4, 5, 6, 7, 8, 9, 0(10), 11, 12, 13, 14, 15, 16
- Channel selection for Live Viewing and Playback mode, Password inputting,
- Channel selection by pushing the button 1, 2, 3, …, 15, 16
z 8ch DVR : 1, 2, 3, 4, 5, 6, 7, 8,
- Channel selection for Live Viewing and Playback mode, Password inputting.
z 4ch DVR : 1,2,3,4 : It can be used for channel & password change.
6. Direction/select button
z UP: Used to move the cursor up; change possible values in the setup menu; under
PTZ control sub menu, used to move camera; or used to adjust focus.
z DOWN: Used to move the cursor up; change possible values in the setup menu; under
PTZ control sub menu, used to move camera; or used to adjust focus.
z LEFT: Used to change possible values in the setup menu. Under PTZ control menu,
used to move the camera left or used to do Zoom Out; At playback mode, used to
decrease playback speed.
z RIGHT: Used to change possible values in the setup menu. Under PTZ control menu,
used to move the camera left or used to do Zoom In; At playback mode, used to
increase playback speed.
z OK: Used as a selection key. Under PTZ control menu, used to be interchanged P/T
mode with Z/F mode
7. IR receiver
z Remote control signal receiver
8. Jog/Shuttle
z Shuttle: Multi-speed forward/reverse playback. Under Network Setup sub menu,
used to input parameters fast.
z Jog: Frame by frame search.
9. USB connector in the front panel
z This connector is for USB Memory stick to back up the image
z USB Mouse is available.
