Arrow Manual Console Reference 121
Global Insert Effects
These buttons globally switch all Console inserts to either pass all UAD insert effect
processing to the DAW (print wet) or not (monitor wet but print dry). See the Insert
Effects Overview additional details.
Insert Effects can also be individually switched on a per-channel basis (see Channel
Insert Effects). The Global Insert Effects switches override all the individual Channel
Insert Effects settings.
Important: UAD plug-in processing in Console’s Unison and auxiliary inserts
is always routed to the DAW (when recording the AUX channels), regardless of
the current Insert Effects setting (Unison and aux insert processing is always
recorded).
UAD REC (print all wet)
When this switch is lit RED and the UAD MON switch is off, all insert
effects on all channels are routed to the DAW.
UAD MON (print all dry)
When this switch is lit BLUE and the UAD REC switch is off, no insert
effects on any input channels are routed to the DAW (except Unison and aux
processing, which is always recorded).
Both UAD REC and UAD MON (print wet and dry)
When both switches are lit YELLOW, some individual channels are recorded
with insert processing and some are recorded dry, as determined by the
Channel Insert Effects switches. Clicking one of the global insert effects
switches will override the individual channel insert effects settings.
Show Strips
These switches show and hide the visibility of the auxiliary return strips and/or the
control room options strip. By default, these strips are not visible. The strips are visible
when its SHOW switch is lit.
The SHOW switches off (left) and on (right)
