Universal Audio Arrow User Manual

Arrow Manual Console Plug-In Inserts 148
Channel Strips
Channel Strips are where all UAD plug-ins within a channel’s four standard inserts can
be displayed and controlled within a single editor window.
Note: Unison plug-in editors in preamp channels are not included within Channel
Strips. However, Unison plug-ins and their settings are stored within Channel
Strip Presets.
Channel Strip editor window
Channel Strip View Enable
To merge all of a channel’s standard insert plug-ins into
a single window, click the Channel Strip Enable switch
within any plug-in in any channel insert.
To disable Channel Strip mode and return to viewing
the channel plug-ins in individual windows, click the
switch again.
Console Channel
Channel Strip View
Enable/Disable
Open Channel Strip Presets Manager
All Standard
Insert Plug-Ins
In Channel
UAD
Toolbar
Plug-In
Controls
Click the Enable switch to activate
Channel Strip view

Universal Audio Arrow Specifications

General

Type	Audio Interface
Connectivity	Thunderbolt 3
Input Channels	2
Output Channels	2
Simultaneous I/O	2 x 4
Preamps	2
Phantom Power	Yes
A/D Resolution	24-bit/192 kHz
Analog Inputs	2 x XLR/TRS Combo
Headphones	1 x 1/4"
Thunderbolt Ports	1 x Thunderbolt 3
Power Supply	Bus powered
Software	UAD Software
Compatibility	Mac, Windows
Analog Outputs	2 x 1/4" TRS
