Arrow Manual Device Drivers 240
Driver I/O Table
The table below lists the I/O channel numbers and names for all Core Audio / ASIO
streams available at default I/O Matrix Panel settings.
Tip: For convenient reference with DAWs that don’t display driver I/O channels by
name, print this page.
Custom I/O Routes
The default I/O routes can be easily changed in the I/O Matrix Panel within the Console
Settings window. See the I/O Matrix Overview for related information.
Driver I/O Table Notes
The number at the left of both columns is the channel number used by the DAW if
the channel names are not displayed by the DAW.
At sample rates of 176.4 kHz and 192 kHz, AUX 2 and VIRTUAL channels are
unavailable.
Arrow Default I/O Table
INPUTS OUTPUTS
1 MIC/LINE/Hi-Z 1 1 MON L
2 MIC/LINE 2 2 MON R
3 MON L* 3 VIRTUAL 1†
4 MON R* 4 VIRTUAL 2†
5 VIRTUAL 1* 5 HP L
6 VIRTUAL 2* 6 HP R
7 AUX1 L*
8 AUX1 R*
9 AUX2 L*
10 AUX2 R*
*Software Outputs
(for DAW inputs)
†Software Outputs
(for Console inputs)
