Arrow Manual Console Overview 78
Console Plug-In Inserts Overview
The UAD plug-in inserts within each input and auxiliary strip is where UAD Powered
Plug-Ins are selected and used for Realtime UAD Processing within Console.
Both of Arrow’s analog preamp inputs have a special dedicated Unison insert in addition
to four standard inserts. Both virtual inputs, and both auxiliary returns, also have
four standard inserts each. Therefore, up to five UAD plug-ins can be serially chained
(stacked) per channel within the constraints of available DSP resources.
Note: For complete details, see Console Plug-In Inserts.
Channel Inserts
Unison Insert
Arrow’s Unison technology is activated when a Unison-enabled UAD
plug-in is loaded in the special dedicated Unison insert slot located
above the preamp options (as shown at right, outlined in red).
Note: Audio on preamp channels is processed by the Unison
insert (if populated) before the channel inserts.
The special dedicated Unison insert is only available on Arrow
preamp channels. However, Unison inserts are operated exactly the
same way as standard channel inserts. See the Unison chapter for
related information.
Inserts Rec/Mon
Indicator
(click to switch)
Record/Monitor Indicator
(INSERTS view only)
Channel Strip Presets
(click for popover)
Standard
(non-Unison)
Insert Slots
1 – 4
Disabled Plug-In
(gray background)
Empty Insert
(click to assign)
Channel Insert Effects Switch
(INSERTS view only)
Offline Plug-In
(red background)
Active Plug-In
(click to edit)
Inserts
Display
Unison Insert
To Next Page
