Universal Audio Arrow User Manual

Arrow Manual Using UAD Plug-Ins 214
Load/Save Preset
Preset/Settings Menu
The Preset/Settings menu is used to load/save plug-in presets and copy/
paste plug-in settings when UAD plug-ins are used within a DAW.
To access the Preset/Settings menu, click the folder icon in the UAD
Toolbar, then select an item from the drop menu.
Tip: When using UAD plug-ins within Console, use Console’s Presets
Manager instead for its improved functionality.
The Preset load/save features support presets but not banks. To load and save banks, use
the DAW’s bank management feature (if available).
When Load Preset or Save Preset is selected from the Preset/Settings Menu, the
standard operating system load/save file dialogs are presented. Preset files can then be
loaded (if the plug-in is the same type), or saved to any disk location.
Copy/Paste Settings
Settings can copied and pasted directly between UAD plug-ins
(within the Preset/Settings Compatibility guidelines) without
using the interim step of creating a preset file.
To copy/paste settings between UAD plug-ins, select Copy
Settings from the drop menu of the source plug-in, then select
Paste Settings from the drop menu of the destination plug-in.
Note: If the menu displays “Cannot Paste Settings,” then settings were not copied
first or the paste destination has incompatible settings.
Default Preset Location
When the load/save functions are used, the OS load/save file dialogs are automatically
directed to the default preset location. Although UAD presets can be loaded from (and
saved to) any disk location, using the default preset location automatically organizes all
your presets of the same UAD plug-in title within the same folder.
The Presets folder path below is the parent folder for all UAD plug-in presets. Within
the parent folder is a subfolder for each individual UAD plug-in title, and the subfolder
contains all the presets for that UAD plug-in.
Windows:
• C:\Program Files (x86)\Universal Audio\Powered Plugins\Presets
Mac:
• /Library/Application Support/Universal Audio/Presets

Universal Audio Arrow Specifications

General

Type	Audio Interface
Connectivity	Thunderbolt 3
Input Channels	2
Output Channels	2
Simultaneous I/O	2 x 4
Preamps	2
Phantom Power	Yes
A/D Resolution	24-bit/192 kHz
Analog Inputs	2 x XLR/TRS Combo
Headphones	1 x 1/4"
Thunderbolt Ports	1 x Thunderbolt 3
Power Supply	Bus powered
Software	UAD Software
Compatibility	Mac, Windows
Analog Outputs	2 x 1/4" TRS
