Universal Robots OEM Control Box User Manual

5. Mechanical Installation
5.1. Working Environment Guidelines
Follow these guidelines to ensure reliable operation of the OEM Control Box:
l Keep free from dust and dirt.
l Keep away from water, solvents, and chemicals.
l Keep ambient air temperatures flowing into the fan within 0–50°C.
l Keep the aluminum controller frame temperature within 0–65°C.
5.2. Mounting the OEM Control Box
Use the four mounting brackets to mount the OEM Control Box, see the following illustration. For
dimensional drawings, refer to section 7.4. Dimensional Drawings [mm] on page19.
For the product dimensions, refer to section 7.3. Dimensions on page18.
OEM Control Box 12 Installation Guide
5. Mechanical Installation
Copyright © 2019 by UniversalRobotsA/S. All rights reserved.
