Universal Robots OEM Control Box User Manual

Use the Mini DisplayPort to connect a monitor. The output video stream is the same as in the
Teach Pendant port.
6.1.2. Teach Pendant, Remote Control, Local Control
Connecting a Teach Pendant
1. Connect the Teach Pendant cable to the Teach Pendant port.
The Teach Pendant powers on in a fault state and the Robot Arm brakes engage.
2. Press Re-Initialize to clear the fault state and power on the Teach Pendant.
3. Once the Teach Pendant is restarted, exit the start-up screen.
4. In the Header, tap Installation and select Safety.
5. Under Safety, tap Hardware.
6. In the Teach Pendant drop-down menu, select Yes.
If you are prompted to use a password, insert the Safety Password and tap Unlock.
Installation Guide 15 OEM Control Box
6. Connecting External Devices
Copyright © 2019 by UniversalRobotsA/S. All rights reserved.
