Upright NX15 Service And Parts Manual

2. Operation Manual Page 14
Inspection and Maintenance Schedule
I NSPECTION AND M AINTENANCE S CHEDULE
The Complete Inspection consists of periodic visual and operational checks, along with periodic minor
adjustments that assure proper performance. Daily inspection will prevent abnormal wear and prolong the
life of all systems. The inspection and maintenance schedule should be performed at the specified
intervals. Inspection and maintenance shall be performed by personnel who are trained and familiar with
mechanical and electrical procedures.
WARNING
!
!
Before performing preventative maintenance, familiarize yourself with the operation of the machine.
Always block the elevating assembly whenever it is necessary to perform maintenance while the
platform is elevated.
The daily preventative maintenance checklist has been designed for machine service and maintenance.
Please photocopy the Daily Preventative Maintenance Checklist and use the checklist when inspecting
the machine.
D AILY P REVENTATIVE M AINTENANCE C HECKLIST
M AINTENANCE T ABLE K EY
I NTERVAL
Y = Yes/Acceptable
N = No/Not Acceptable
R = Repaired/Acceptable
P REVENTATIVE M AINTENANCE R EPORT
Date: ______________________________________
Owner: _____________________________________
Model No:___________________________________
Serial No: ___________________________________
Serviced By:_________________________________
___________________________________________
COMPONENT INSPECTION OR SERVICES Y N R
Battery
Check electrolyte level.
Check battery cable condition.
Chassis
Check hoses for pinch or rubbing points.
Check welds for cracks.
Control Cable Check the exterior of the cable for pinching, binding or wear.
Controller Check switch operation.
Drive Motors Check for operation and leaks.
Elevating Assembly Inspect for structural cracks.
Emergency Lowering System Operate the emergency lowering valve and check for serviceability.
Entire Unit Check for and repair collision damage.
Hydraulic Fluid Check fluid level.
Hydraulic Pump Check for hose fitting leaks.
Hydraulic System Check for leaks.
Labels Check for peeling, missing, or unreadable labels & replace.
Platform Deck and Rails
Check welds for cracks.
Check condition of deck.
Tyres Check for damage.
