Upright NX15 Service And Parts Manual

Specifications
Page 15 2. Operation Manual
S PECIFICATIONS
*Specifications are subject to change without notice. Hot weather or heavy use may affect performance.
Refer to the Service Manual for complete parts and service information.
The MX19 meets or exceeds all applicable CE and GS machinery directive requirements.
ITEM MX19
Platform Size (Inside minimum)
Standard w/Deck
0,57 m x 2,5 m (22.5 in. x 98.5 in.)
Maximum Platform Capacity
Standard w/Deck Extension
227 kg (500 lbs.)
Maximum Number of Occupants
Standard w/Deck Extension
2 People indoors/1 person outdoors
on Extension
1 Person
Height
Working Height
7,8 m (25 ft. 6 in.)
Maximum Platform Height
5,8 m (19 ft.)
Maximum Drivable Height
5,8 m (19 ft.)
Dimensions
Weight
1406 kg (3100 lbs.)
Overall Width
760 mm (30 in.)
Overall Height (Lowered)
2,02 m (79.5 in.)
Overall Length (Deck in)
1,60 m (63 in.)
Drive Speed
Platform Lowered
3,7 km/h (2.3 mph)
Platform Raised
1,0 km/h (0.62 mph)
Energy Source
24 V battery pack (4-220 A hour, 6 V batteries, min. wt. 26,3 kg
[58 lbs.] each), 4 HP DC electric motor
System Voltage 24 V DC
Battery Charger 20 A, 240 V AC 50 Hz, Automatic
Hydraulic Tank Capacity 12,9 L (3.4 US gal.)
Maximum Hydraulic System Pressure 234 bar (3400 psi)
Hydraulic Fluid
Normal above 32° F [0° C]
ISO #46
Low Temp. below 32° F [0° C]
ISO #32
below 0° F [-17° C]
ISO #15
Lift System One Single Stage Lift Cylinder
Drive Control Motor Control
Control System
Control Handle with Interlock Switch, Rotary Drive/Lift Switch,
and Red Mushroom Emergency Stop Switch
Drive System Dual Front Wheel Hydraulic Motors
Tyres 30,5 cm (12 in.) diameter solid rubber, Non-marking
Turning Radius (inside) 150 mm (6 in.) Inside
Maximum Gradeability 25% (14°)
Wheel Base 1,23 m (48.5 in.)
Guardrails 1,10 m (43 in.)
Toeboard 150 mm (6 in.)
Noise Level
