Upright NX15 Service And Parts Manual

Page 6-4
Illustrated Parts Breakdown - Chassis Assembly
MX19
Chassis Assembly
503501-000
1 065620-025 CHASSIS 1
2 503696-000 HYDRAULIC TANK ASSEMBLY 1
3 066307-005 LADDER WELDMENT 1
4 065971-021 POTHOLE BAR (RH) 1
5 065971-020 POTHOLE BAR (LH) 1
6 065650-001 CHASSIS DOOR (RH) 1
7 065657-002 CHASSIS DOOR (LH) 1
8 057082-000 CLAMP BOLT ASSEMBLY 2
9 503511-001 MOTOR MOUNT ASSEMBLY (RH) 1
10 503511-000 MOTOR MOUNT ASSEMBLY (LH) 1
11 503609-001 WHEEL COVER WELDMENT (MAIN PLATE) 1
12 503686-000 TIE DOWN RING 1
13 503686-001 TIE DOWN RING 1
14 503687-000 CYLINDER, HYDRAULIC (STEERING) 1
15 503622-000 CYLINDER, HYDRAULIC (POTHOLE) 2
16 503755-000 CASTLE NUT 1 1/8 2
17 502152-000 SPLIT PIN 2
18 503677-000 PLAIN WASHER 2
19 504351-001 WHEEL 4
20 504157-000 ROLLER BEARING 2
21 503673-000 PLAIN BUSHING 8
22 503672-000 PLAIN BUSHING 8
23 011848-019 PIVOT PIN (POTHOLE CYLINDER, BODY END) 2
24 011848-036 PIVOT PIN (POTHOLE CYLINDER, ROD END) 2
25 503760-000 PLAIN BUSHING 2
26 503676-000 DU WASHER 4
27 069199-001 BATTERY CHARGER 1
28 501074-000 BATTERY (6V 220ah , T605) 4
29 504536-000 PUMP MOTOR 1
30 - PUMP 1
31 502139-001 BATTERY ANGLE 2
32 058912-000 TILT SENSOR SWITCH 1
33 503679-000 SLIDE, BATTERY COMPARTMENT 4
34 503800-001 MANIFOLD, HYDRAULIC 1
35 502483-000 ECU 1
36 502492-000 MOTOR CONTROLLER 1
37 503609-000 REAR MUDGUARD (LH) 1
38 503681-000 STOP BRACKET 2
39 503626-001 STEERING LINK PLATE 2
40 501227-002 PIVOT PIN, STEERING CYLINDER 2
41 503757-000 SUPPORT PLATE, PCB 1
42 502494-000 FUSE 175A 1
43 501877-000 FUSE HOLDER 2
44 056066-004 NYLOCK NUT, M4 - 8 1
45 503758-000 ADAPTOR PLATE, FUSE 1
46 503759-000 LATCH SPACER, BATTERY 2
