Upright X Series Service & Parts Manual

7-6
7.2
Illustrated Parts Breakdown
X20N/X20W/X26N/X31N Work Platform
Section
1 66051-001 BASIC ASSEMBLY 1
2 66008-010 CONTROL MODULE 1
3 66009-010 POWER MODULE 1
4 66055-010 GUARDRAIL INSTALLATION 1
* 11828-008 SCREW 1/4-20 X 1 FLAT HD SOC 2
6 05832-000 WASHER LOCK 1/4 2
7 66060-010 DECAL KIT INSTALLATION 1
8 66012-000 CONTROL CABLE ASSY 1
* 66061-010 HOSE KIT INSTALLATION 1
10 66013-012 CONTROLLER ASSEMBLY 1
11 15796-000 BATTERY 6V 220AMP (WET) 4
* 15796-001 BATTERY 6V 220AMP (DRY) 4
12 63944-011 CHARGER 1
13 11253-006 SCREW HHC 5/16-18UNC X 3/4 8
14 11248-005 NUT 5/16-18 HEX 8
15 64195-001 CABLE ASS’Y X 12 3
16 64195-063 CABLE ASS’Y X 63 LG 1
17 64195-128 CABLE ASS’Y X 128 LG 1
18 66014-010 ELECTRICAL BOX ASSEMBLY 1
19 20541-025 CLAMP 1
20 66017-010 CONTROL VALVE ASSEMBLY 1
21 11941-005 FITTING STRAIGHT 6MB- 6 MJ 5
* 65369-099 HOSE GUARD, NYLON 1.5FT
23 66713-001 DOOR HINGE 1
24 11240-012 WASHER 3/4 FLAT 4
25 26551-005 RIVET. POP 10
26 11252-032 SCREW HHC GR5 1/4-20 X 4 3
27 11240-004 WASHER FLAT 1/4 DIA 3
28 66179-000 VALVE 1
29 65754-001 CABLE 1
30 66368-000 BRACKET 1
31 63664-008 ORIFICE, HYDRAFORCE #7051070 1
32 11252-006 SCREW HHC 1/4-20 X 3/4 4
33 11248-004 NUT 1/4-20 HEX 6
34 61796-099 GROMMET .25FT
35 29945-011 LEVEL SENSOR 1
36 66786-000 WELDMENT, TILT ALARM COVER 1
FINAL ASSEMBLY
X20W
66050-010
ITEM PART DESCRIPTION QTY.
ITEM PART DESCRIPTION QTY.
37 11275-003 SCREW #10-32 X 3/8 6
38 11821-006 SCREW BUTTON HD 1/4-20 X 3/4 2
39 14099-018 SCREW HHC GR5 PLTD 3/4-10 X 2 1/4 4
40 11238-002 WASHER #10 LOCK 8
41 11250-012 NUT 3/4-10 HEX 4
42 29620-002 CONN. BUTT 14-16 GA 2
43 29601-015 CONN. RING 14-16 GA 3/8 4
44 29601-013 CONN. RING 14-16 GA #10 4
45 29931-003 CONN. F PUSH 14-16 GA .25 13
46 29610-002 CONN. FORK 14-16 GA #8 31
47 29616-005 CONN. PUSH 10-12 GA .25 1
48 11252-008 SCREW HHC GR5 1/4-20 UNC X 1 2
49 66056-010 DECK EXTENSION INSTALLATION 1
50 66764-000 SHIM 12GA A/R
51 11254-008 SCREW HHC 3/8-16 X 1 2
52 29615-002 CONN. F PUSH 14-16GA .187 7
53 29617-002 CONN. M PUSH 14-16 GA .25 3
54 11240-005 WASHER 5/16 FLAT 2
55 66763-000 SHIM 16GA A/R
56 66762-000 SHIM 20GA A/R
57 66713-000 DOOR HINGE 2
58 29461-099 WIRE 14 GA BLACK 15FT
59 66043-000 SWITCH MOUNT 1
60 10154-000 TERM COVER 8
* 66769-000 ELECT SCH. REF
* 66781-000 HYD SCH REF
63 64195-004 CABLE ASSY X 4 LG 1
64 64195-009 CABLE ASSY X 9 LG 1
65 29601-040 CONN. RING 16-14 5/16 3
* 29452-099 WIRE 16 AWG BLK 3FT
67 29496-099 WIRE 16 AWG 2 COND 50FT
68 65373-006 SWITCH 1
69 11154-020 THRUST WASHER 2
70 65373-005 SWITCH MAGNET 1
71 66042-000 MOUNT MAGNET 1
* Not shown
