Valeo REVO-E - Overview of High-Voltage Cable Harnesses; Components (400 V AC; 600 V DC)

303
REVO-E Heat pump 3 Assemblies and components
3.3 Overview of high-voltage cable harnesses / components (400V AC / 600V DC)
Fig. 3 Overview of high-voltage cable harnesses / components (400V AC / 600V DC)
1 - High-voltage power supply of the frequency converter 600V DC
2 - High-voltage power supply of the compressor 3x 400V AC
1
2
Frequency converter
Compressor with 3x 400V AC e-motor
600V DC
-
> 3x400V AC
