REVO-E Heat pump 9 Removal/ installation of components
9.3.2 Installation of the condenser module
• The installation of the condenser module is carried out
in reverse order.
Thereby the gaskets of the refrigerant circuit are to be
replaced!
• Do the final work according to 9.3.
Fig. 901 (exemplarily)
1 Frequency inverter design cover
2 Compressor design cover
3 Protective grille
4 Attachment condenser module
5 Pipe pipe group 4-way reversing valve - outer heat exchanger
6 Pipe collector - outer heat exchanger
1
3
2
5
6
4
