Valeo REVO-E - Expansion valves removal; installation

903
REVO-E Heat pump 9 Removal/ installation of components
9.4 Expansion valves removal/
installation
9.4.1 Positions of the expansion valves and the
associated contact sensors
Fig. 902 Positions of expansion valves and the associated contact sensors
Contact sensor expansion
valve outer heat exchanger
Contact sensor expansion
valve left-hand inner heat
exchanger
Expansion valve
left-hand inner
heat exchanger
Expansion valve right-hand
inner heat exchanger
Contact sensor expansion
valve right-hand inner heat
Expansion valve outer
heat exchanger
exchanger
